underfloor heating digital thermostat
Weekly programmable with touch screen
can loop on every week every day
General
- BYC07AH Touch Screen Heating Thermostat with weekly programming adopts the latest single-chip computer control technology. It has the high reliability and powerful anti-jamming.
- Setting daily 4 periods of time and the setting temperature.
- The selection for manual control or automatic periods of time control.
- The application of electric heating of the electric heating equipment and Water heating system of electric heating re actuator control.
- Easy operation and utility.
- Touch screen input, Nice looking and easy-cleaning.
- Kinds of periods of time modes. 5+2/6+1/7
- The maximum switch power is 3600W.
- The wide voltage input: AC75-265V 50Hz/60Hz
- Mini size junction box. It is suitable for the entire world.
- The clock continues when power fail and it won’t affect the period of time settings.
- Flame retardant and safe.
- Extra over heating sensor label length: 3 meters
Technical parameters
- Power Supply: 75-250VAC(24± 10% Optional), 50/60 Hz
- the max number switch power is 3600W
- Set point Range: 5 to 35°C (programmable)
- Inside sensor measurement range: 0 to 40 °C
- External sensor measurement rang:0 to 90 °C
- Inside Sensor: NTC B=3380 10k @25degrees Celsius
- Extra Sensor: Length=3M NTC B=3380 10k @25degrees Celsius
- Setting Unit: 0.5°C / step
- Indication Accuracy: 0.1°C
- Touch LCD screen, display area size: 60 x 45 mm
- Dimension: 86 x 86 x 12mm ( H x W x D )
- Weight: 180 g/piece
- Inner Box Size: 100 x 100 x 60 mm
Dimensions: unit: mm
