Digital LCD thermostat with programmable thermostat with modbus rs485

FOB Reference Price:Get Latest Price
$1.00 - $20.00 / Pieces | 100 Piece/Pieces (Min. Order)
Type:
Air Conditioning HVAC Systems
Report Suspicious Activity
Overview
Quick Details
Brand Name:
BFA
Display Type:
LCD
Programmable:
Programmable
Certification:
TUV CE
Type::
Temperature Controller
Control Type::
Digital
Supply Ability
Supply Ability:
1500 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
White box(inner)100*100*6mm;
Brown cartons(outside) 530*330*220mm for 50pcs thermostat
Port
Ningbo or Shanghai

Digital LCD  thermostat with modbus rs485



Digital LCD thermostat with programmable and floor sensor
Certification: TUV CE
Button can shine.

85-250 VAC (24VAC)

C16.GH1   3A
C16.GH3  16A


Basic function:
1. Recommended for control of underfloor heating and electrical heating.
2. Electronic on/off control up to 3A or 16A
3. Six daily programmable time settings, from Mondays to Sundays
4. Large Back-lit display, LCD screen, easy-to-see and read
5. Infrared remote-controlled function(option)
6. Built-in sensor and floor sensor
7. Two work mode switchover: (programmable, non programmable)
8. Display temperature recalibrates
9. Low temperature protection function
10. Surveys, display and set room temperature
11. Memory function: Parameters are permanently held in memory and retained during power outages
12. Anti-freezing protection
13.2-sensor: Room sensor with floor limiter sensor  ( floor limiter sensor is option)


Product Specifications:
Voltage:  85-250 VAC, 50/60Hz  24VAC ( option)
Differential Temperature: 1 ° C Max
Setting Temperature Range: 5° C~35° C
Mounting: Mounts directly onto wall or wall-box
Temperature range: 0° C - 40 ° C
Sensor type: NTC
Color: White ivory
Relative humidity: < 85% (23 ° C)
Dimensions: 86mm× 86mm× 13mm(H/W/D)
